Product Description:
The Magnetic Stripe Laying Machine is a cutting-edge solution designed for efficiently handling the production of magnetic stripes for various applications. This advanced equipment is commonly referred to as a Magnetic Strip Coiling Machine or Magnetic Stripe Spooling Machine.
Key features of this state-of-the-art machine include:
- Automatic operation for enhanced productivity and ease of use
- PLC controlled system for precise and reliable performance
- Servo motor controlled sheet feeding for accurate processing
- Adjustable pressure laying rollers for customization according to specific requirements
- Waste system for magnetic stripe back foil, ensuring efficient material handling
- Air shaft loading system for seamless integration and operation
- Precise temperature control for consistent and high-quality results
The Magnetic Stripe Laying Machine is capable of handling a quantity of 5 to 8 magnetic tapes simultaneously, providing flexibility and scalability for various production needs. It supports a product thickness range from 0.2mm to 0.8mm, catering to a wide range of magnetic stripe applications. Additionally, users have the option to work with 5 to 8 magnetic tapes based on their specific requirements.
With an approximate air consumption of 80L/min, this machine offers energy-efficient operation while ensuring optimal performance. Whether you need a Magnetic Strip Coiling Machine, Magnetic Stripe Spooling Machine, or Magnetic Strip Splicing Machinery, this versatile equipment is designed to meet your production demands with precision and efficiency.
Features:
- Product Name: Magnetic Stripe Laying Machine
- Air Source: 6 kg/cm2
- Laying Accuracy: ±0.15mm
- Temperature Range: 0-400℃ (adjustable)
- Quantity of Magnetic Tapes: 5~8
- Product Thickness Range: 0.2mm~0.8mm
Technical Parameters:
| Product Name | 8 Heads 12.7mm Automatic Magnetic Stripe Laying Machine YMSL-1000 For Cards |
| Applicable Materials | Paper card, PVC, ABS, PET, PVC/ABS composite materials, etc. |
| Power Supply | AC 380V/50 HZ |
| Total Power | 8.5KW |
| Product Category | Magnetic Stripe Laying Machine |
| Sheet Layout Options | 3X8, 4X8, 5X5 (optional) |
| Temperature Range | 0-400℃ (adjustable) |
| Product Thickness Range | 0.2mm~0.8mm |
| Quantity of Magnetic Tapes | 5~8 |
| Air Source | 6 kg/cm2 |
Applications:
The YL YASB-1 Magnetic Stripe Laying Machine, also known as the Magnetic Stripe Spooling Machine, is a high-quality device originating from China. With a minimum order quantity of 1 set and a negotiable price, this machine offers flexibility in payment terms including T/T, Western Union, and MoneyGram.
Designed to handle a product thickness range of 0.2mm to 0.8mm, the YASB-1 model has a remarkable productivity rate of 1000-1300 sheets per hour. This Magnetic Band Layering Device is suitable for various materials such as paper card, PVC, ABS, PET, PVC/ABS composite materials, etc.
The YASB-1 model, also known as the Magnetic Tape Rollout System, can accommodate 5 to 8 magnetic tapes simultaneously. Its efficient operation makes it an ideal choice for companies looking to enhance their card production process.
With a supply ability of 1 set every 25-30 days and a delivery time of 25-35 days, the YL YASB-1 ensures a consistent and reliable performance. The machine is delivered in export standard plywood case packaging, guaranteeing its safety during transportation.
The 8 Heads 12.7mm Automatic Magnetic Stripe Laying Machine YMSL-1000 For Cards by YL is a versatile solution for businesses seeking to streamline their card manufacturing operations. Whether you require high-volume production or precision in magnetic stripe application, this machine is a top choice for your needs.
Support and Services:
The Product Technical Support and Services for the Magnetic Stripe Laying Machine include:
- Installation support for setting up the machine correctly.
- Operation training to ensure users know how to operate the machine efficiently.
- Troubleshooting assistance to address any issues that may arise during operation.
- Maintenance guidance to help keep the machine in good working condition.
- Software updates and upgrades to enhance machine performance.
Packing and Shipping:
Product Packaging:
The Magnetic Stripe Laying Machine is carefully packaged to ensure its safety during transportation. Each machine is wrapped in protective materials and placed in a sturdy cardboard box to prevent any damage.
Shipping:
Orders for the Magnetic Stripe Laying Machine are processed promptly and shipped using reliable courier services. Customers can track their shipment using the provided tracking number to know the exact delivery date.
FAQ:
Q: What is the brand name of the Magnetic Stripe Laying Machine?
A: The brand name of the Magnetic Stripe Laying Machine is YL.
Q: What is the model number of the Magnetic Stripe Laying Machine?
A: The model number of the Magnetic Stripe Laying Machine is YASB-1.
Q: Where is the Magnetic Stripe Laying Machine manufactured?
A: The Magnetic Stripe Laying Machine is manufactured in China.
Q: What are the accepted payment terms for purchasing the Magnetic Stripe Laying Machine?
A: The accepted payment terms for purchasing the Magnetic Stripe Laying Machine are T/T, Western Union, and MoneyGram.
Q: What is the supply ability of the Magnetic Stripe Laying Machine?
A: The supply ability of the Magnetic Stripe Laying Machine is 1 set per 25-30 days.
